FEATURES:
-
Constant Q Filters
-
Professional long throw slide faders
-
Switchable 6dB / 12dB fader range
-
Switchable 40Hz 12dB/Oct HPF
-
Switchable bypass with LED indicator
-
Sweepable 40Hz -100Hz 12dB/oct HPF
-
Built-in soft limit protection
-
XLR/ 1/4‚ jack inputs / outputs
-
Ground lift switch
-
4 Segment level and clip LED display
SPECIFICATIONS
| Weight | 4kg |
| Dimensions | 482.6mm x 170mm x 88 mm |
| Dynamic Range | 108dB |
| Frequency Response | 20Hz - 20kHz |
| Inputs | 1 x XLR, 1 x 6.3mm Jack |
| Low Cut | 50Hz 12dB/Oct HPF |
| Outputs | 1 x XLR, 1 x 6.3mm Jack |
| Range | /- 6dB or /-12dB |
| Signal-to-Noise Ratio | 90dB |
| THD | 0.004% |
HOW IT WORKS:
The WHARFEDALE Q130 EQUALIZER GRAPHIC 30 BAND 1/3 OCTAVE works by providing complex tonal correction and feedback elimination. It offers a single channel with 30 bands, constant Q filters, professional long throw slide faders, and switchable 6dB/12dB fader range. It also has a built-in soft limit protection, 4 segment level and clip LED display, and XLR/1/4‚ jack inputs/outputs.PRODUCT FAQ:
Q: What is the dynamic range of the WHARFEDALE Q130 EQUALIZER GRAPHIC 30 BAND 1/3 OCTAVE?
A: The dynamic range of the WHARFEDALE Q130 EQUALIZER GRAPHIC 30 BAND 1/3 OCTAVE is 108dB.
Q: What type of inputs and outputs does the WHARFEDALE Q130 EQUALIZER GRAPHIC 30 BAND 1/3 OCTAVE have?
A: The WHARFEDALE Q130 EQUALIZER GRAPHIC 30 BAND 1/3 OCTAVE has 1 x XLR, 1 x 6.3mm Jack inputs and 1 x XLR, 1 x 6.3mm Jack outputs.
